Product
|
|
|
General
|
| Print speed |
A4:22ppm A3:12ppm |
| Control panel |
4 Line LCD |
| Processor speed |
833Mhz |
| Memory |
DDR4/1GB |
| Recommended Monthly Page Volume |
4000pages/month |
| Maximun Monthly duty cycle |
60000 pages/month |
| Connectivity |
USB2.0
IEEE 802.3 10/100/1000Base-Tx
WiFi（2.4G/5G）IEEE 802.11a/b/g/n （Option） |
| Power |
110V Model：AC100-127V,50/60Hz,10A
220V Model：AC220-240V,50/60Hz，5A |
| Power Consumption |
Average：under 550W
Ready：under 80W
Sleep：under 1W
Power off：under 0.5W |
| Energy Star standards |
Meets ENERGY STAR 3.2 standards |
| Noise |
Ready:less than30dB（A）
Print、Scan:less than52dB（A）
Copy:less than55dB（A） |
| Operating Environment |
Temperature： 10-32℃
Humidity： 20-80%
Altitude： China:below 2000m Other countries：below 3000m |
|
|
Print
|
| Print Speed |
22ppm |
| Duplex Print Speed |
16ipm |
| First Print out time |
less than8.5S |
| Print Languages |
GDI |
| Duplex printing |
Automatic double-sided as standard |
| USB disk printing |
No（Scan to USB） |
| Mobile printing |
Option：PWF-230（WiFi model）
Android/iOS APP、Airprint、Mopria |
| Operation system |
Windows7/Windows8/Windows8.1/ Windows10/ Windows11/ Windows server/2008/2012/2016/2022
（32/64 Bit）
Mac10.10/10.11/10.12/10.13/10.14/10.15/11/12/13/14/14.1/14.2/14.3
Linux：ubuntu16.04、18.04、20.04、22.04/Debian 10.0/Centos 7（32/64 Bit）、Astra Linux Special Edition V1.6/Redhat 8.2.0and above/ Centos 8.2(64 Bit) |
| Others |
Mixed Size Printing、Security printing，Brochure Printing，Border-free Printing、Automatic Print Selection，Printing automatically skips blank pages |
|
|
Copy
|
| Copy Speed |
A4:22ppm A3:12ppm |
| Duplex copy speed |
7ppm |
| First copy out time |
9.5s |
| Copy mode |
Text/Image, Image, Text, Automatic |
| Copy Resolution (max.dpi) |
Max600x600dpi |
| Maximum copy pages |
999 pages |
| Copy reduce / enlarge settings |
25-400% |
| Other functions |
Document copying, bill copying, all-in-one copying, watermark copying, collate, margin adjustment, margin erase, edge-to-edge scanning, Auto orientation |
|
|
Scan
|
| Scanning Technology |
CIS |
| Scanner type |
Flatbed+RADF |
| Scan mode |
Color, grayscale,Mono |
| Scan Speed |
A4 ，300dpi :
ISO 24734：single：30ppm
GB/T 28166-2011 ：single：29ppm |
| Duplex scanning speed |
A4 ，300dpi ：
ISO 24734：Double：14ipm
GB/T 28166-2011 ：Double：14ipm |
| ADF capacity |
100 pages |
| Scan resolution |
Max：600x600dpi |
| Maximum scan size |
Max：A3、11"×17" |
| Scan Destinations |
Scan to PC、Email、SMB、FTP、Usb disk |
| Scanning file formats |
Push scan to SMB，Email，FTP，U disk：TIFF，JPEG，PDF
Push scan to PC（Windows/Mac）：TIFF，JPEG，PDF， OFD, BMP
Pull scan to PC（Windows）：TIFF，JPEG，PDF ，OFD,BMP，PNG |
| Pantum scanning software |
Yes |
| Others |
Original skew, auto crop, hybrid scanning, document scanning, OCR (pull scan) |
|
|
Paper handling
|
| Paper Input Capacity |
Standard：250 Pages
Multipurpose tray：100Pages
Optional tray：550Pages（Maximum：2）
Max：1450Pages |
| Paper output capacity |
250 pages（A4 landscape）、200 pages（A3，80g/㎡） |
| Paper output full detection |
No |
| Options |
PT-230：550 pages（Maximum：2）
PC-230：Cabinet
PWF-230（WiFi module） |
| Media types(single-sided) |
Tissue paper（60-69gsm），Plain pape（70-105gsm），
recycled paper（70-89gsm)，Thick paper（106-216gsm），Postcards, envelopes, label paper |
| Media sizes(single-sided) |
Standard Paper tray： A3, A4, A5 ,JIS B4，JIS B5，ISO B5，11"×17", LTR, 8K, 16K, Legal,Statement, Folio, Oficio， executive
Multipurpose tray:A3, A4, A5， JIS B4，JIS B5，ISO B5， 11"×17", LTR, 8K, 16K，Legal, Statement， Folio，Oficio， executive， postcard，
No.10 Env （envelop），Monarch Env（envelop） ，DL Env （envelop），C6 Env（envelop），C5 Env（envelop），
Customize（ 120×130mm ~297.0×432.0mm
Optional paper tra：A3, A4, A5, JIS B4，JIS B5，ISO B5， 11"×17", LTR, 8K, 16K, Legal,Statement， Folio, Oficio， executive |
| Media weights |
Standard / optional paper tray：60-120g/㎡
Multipurpose tray：60-216g/㎡ |
|
